286 (11 1/4 in)
95
(3 3/4 in)
20x20
(6/8x6/8 in)
327 (12 7/8 in)
89 (3 1/2 in)
60
(2 3/8 in)
534
(21 in)
30 (1 3/16 in)
120
(4 3/4 in)
654
(25 3/4 in)
Figure 25. AIW26 front view
Figure 26. AIW26 side view
Figure 28. AIW26 top view
Figure 30. AIW26 grille side and front views
Figure 31. RAM1 side view
130
(5
1/8 in)
117
(4 5/8 in)
281 (11 1/16 in)
309 (12 3/16 in)
145
(5
3/4 in)
137
(5 3/8 in)
Figure 29. RAM1 top view
4 (3/16 in)
350 (13 3/4 in)
574
(22 5/8
in)
4 (3/16 in)
365 (14 3/8 in)
589
(23 3/16 in)
Figure 27. AIW26 mounting ange side and front views
