Genelec G One User Manual

English 11
SYSTEM SPECIFICATIONS
Frequency response (–6 dB) 67 Hz - 25 kHz
Max. short term sine wave acoustic output on axis in half space, averaged 100 Hz - 3 kHz at 1 m > 96 dB SPL
Maximum long term RMS acoustic output in same conditions with IEC weighted noise (limited by
driver unit protection circuit) at 1 m: > 91 dB SPL
Self generated noise level in free eld at 1 m on axis (A-weighted): < 5 dB
Harmonic distortion at 85 dB SPL at 1 m on axis 70...400 Hz < 3 %
>400 Hz < 0.5 %
Input connector type: 1 RCA female
Input impedance: 7 kOhm:
Crossover frequency, Bass/Treble: 3.0 kHz
Tabletop control operating range: -4 dB at 200 Hz
Bass control operating range in –2 dB steps: 0 to -6 dB at 200 Hz
Bass amplier power (long term output power is limited by driver unit protection circuitry) 25 W
Treble amplier power (long term output power is limited by driver unit protection circuitry): 25 W
Amplier system distortion at nominal output THD+N: < 0.08 %
Mains voltage: 100-240 V AC, 50-60 Hz
Voltage operating range: ±10 %
Power consumption
Standby (ISS active)
Idle
Full output
<0.5 W
5 W
30 W
Bass driver
Treble driver
76 mm (3 in)
19 mm (
3
/
4
in)
Weight: 1.7 kg (3.7 lbs)
Dimensions:
Height including Iso-Pod™ table stand
Height without Iso-Pod™ table stand
Width
Depth
195 mm (7
11
/
16
in)
181 mm (7
1
/
8
in)
121 mm (4
3
/
4
in)
115 mm (4
1
/
2
in)

Genelec G One Specifications

General

Product color	White
Housing material	-
Recommended usage	Universal
Suitable for outdoor use	No
Tweeter	Yes
Speaker type	2-way
Speaker placement	Tabletop/bookshelf
Audio output channels	1.0 channels
Woofer diameter (imperial)	3 \
Tweeter diameter (imperial)	0.75 \
Impedance	- Ω
Sensitivity	93 dB
Frequency range	73 - 21000 Hz
RMS rated power	- W
Audio RCA inputs	1
Connectivity technology	Wired

Weight and Dimensions

Depth	114 mm
Width	121 mm
Height	195 mm
Weight	1400 g
