English 7
Figure 1. Control and connector layout on the rear panel of a G One.
a boost at certain bass frequencies, which the
“Tabletop” function is designed to compensate
for.
Bass
The “Bass” control oers three attenuation levels
for the bass response below 2 kHz, usually
necessary when the loudspeakers are placed
near room boundaries or other situations when
the bass sounds boomy and too dominant. The
attenuation levels are -2 dB, -4 dB and -6 dB. The
-6 dB attenuation is selected by setting both “Bass”
switches to “ON”.
The factory setting for the tone controls is all
in the “OFF” position. This setting produces a
TO WATER OR MOISTURE. NO USER SERVICEABLE PARTS
ELECTRIC SHOCK HAZARD. DO NOT OPEN. DO NOT SUBJECT
L'INTÉRIEUR REMPLAÇABLE PA RL'UTILISATEUR. ADRESSER
RISQUE DE CHOC ÉLECTRIQUE. NE PAS OUVRIR. NE PAS
EXPOSERÀL'EAU OU L'HUMIDITÉ. AUCUN COMPOSANT À
AVERTISSEMENT
WARNING
INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL.
TOUTE RÉPARATIONÀUN PERSONNEL QUALIFIÉ.
292-6010W
MAINS INPUT
50/60Hz30W 100-240 V~
MADE IN FINLANDwww.genelec.com
292-G1BT
This device complies with FCC Part 15 and Canadian ICES-003 radio frequency Class B
emission requirements. Refer to operating manual for full information.
INPUT
BASS -4 dB
BASS -2 dB
ISSDISABLE
LEVEL -10 dB
TABLETOP
292-G1BS
ON
G One
Active Loudspeaker
REFLEX PORT
THREADS FOR
CEILING AND
WALL MOUNTS
TONE CONTROLS
CONNECTOR P
