Owner’s Manual for Mobile Generator 23
General Information
Voltage Selector Switch
The voltage selector mechanically configures the
generator main windings. The unit is equipped with either
a 3- or a 4-position switch. Available configurations for
each are shown in the table below.
Lockout Function
The voltage selector switch is equipped with a lockout
mechanism. When engaged, the switch is locked in
place, preventing configuration changes.
NOTE: See Using the Voltage Selector Switch for
more information.
3-Position Switch 4-Position Switch
Available
Configurations
• Hi wye
• Low wye
• Zig zag
• Hi wye
•Low wye
• Zig zag
•Delta
(000302)
WARNING
Electric Shock. Never change the voltage selector
switch while the engine is running or the controller
is on. Doing so could result in death, serious injury
or equipment damage.
