IDENTIFICATION RECORD
DATA LABEL
Every generator set has a DATA LABEL that contains
important information pertinent to the generator. The
data label, which can be found attached to the gen-
erator’s lower connection box, lists the unit’s serial
number and its rated voltage, amps, wattage capacity,
phase, frequency, rpm, power factor, etc.
WAUKESHA
,
W
I
RATED KW
RATED V
O
LTA
GE
P
O
WER FA
C
T
OR
EN
G
INE RP
M
ALTERNAT
O
R
SU
BTRAN
S
IENT REA
C
TAN
CE
ALTERNAT
O
R TRAN
S
IENT REA
C
TAN
CE
CLAS
S
MODEL
QT
MADE IN
USA
PR
O
D
UC
TI
O
N DAT
E
GENERAC POWER SYSTEMS
,
INC
.
HERTZ
RATED KVA
G
ENERAT
O
R
S
ET DAT
A
RATED AMP
S
ALT RPM
PHA
SE
S
ERIA
L
ROTO
R
STATO
R
WINDING INSULATION AT 2
5
°
C AMBIEN
T
NOTE:
For actual information related to this particular
model, please refer to the Manual Drawing Listing
located at the end of this manual, or to the data
label affixed to the unit.
Generator Model and Serial Number
This number is the key to numerous engineering and
manufacturing details pertaining to your unit. Always
supply this number when requesting service, order-
ing parts or seeking information.


Identification Code
Use this code to obtain important information about
the generator. For example, if the code is ...
SD 100-- A 1 6 5.0 D 18 HB Y N C
– identify the generator as follows:
• SD – Standby diesel generator (“SG” indicates a standby
gaseous fuel unit).
• 100 – Rated output is 100,000 watts (100 kW).
• A – Voltage code (see “Voltage Codes” on this page).
• 1 – Indicates single-phase unit (3 – indicates three-phase
unit).
• 6 – Indicates unit rated 60 Hertz (Hz) (5 – indicates
50 Hz).
• 5.0 – Engine is 5.0 liter (304 cubic inches).
• D – Unit has diesel fuel system (“N” indicates natural
gas; “L” indicates LP Liquid Withdrawal; “V” indicates
LP Vapor Withdrawal).
• 18 – Alternator rpm rating (1,800 rpm); “36” indicates
3,600 rpm.
• H – Unit has an option “H” control panel.
• B – Indicates a brushless unit (“D” indicates a direct
excited unit with brushes and slip rings; “P” indicates a
permanent magnet excitation).
• Y – Unit is equipped with a standard enclosure (“N” indi-
cates no enclosure; “S” indicates unit has an acoustic
enclosure).
• N – Unit does not have an exhaust muffler (“Y” indicates
a muffler has been mounted; “L” indicates a muffler has
been shipped loose with the unit).
• Y – Unit has a main line circuit breaker (“C” indicates
unit has a UL-listed circuit breaker; “N” indicates no
circuit breaker has been mounted).
Groups and Assembly Numbers
The Data Label lists the groups and correspond-
ing assembly numbers for each unit. The assembly
numbers refer to exploded view drawing numbers
that are applicable to the specific generator model.
These drawings are located in the back half of this
manual.
Voltage Codes
The identification code letter following the unit’s kilo-
watt rating is the generator’s “voltage code.” Any one
of the following voltage codes may be listed.
A – 120/240 volts, single-phase, four-lead, 60 Hz
D – 120/240 volts, single- and three-phase, 12-lead, 60 Hz
G – 120/208 volts, three-phase, 12-lead, 60 Hz Broad Range
J – 120/240 volts, three-phase, 12-lead, 60 Hz Broad Range
K – 277/480 volts, three-phase, 12-lead, 60 Hz Broad Range
L – 346/600 volts, three-phase, six-lead, 60 Hz
M – 110/220 volts, single-phase, four-lead, 50 Hz
N – 115/200 volts, three-phase, 12-lead, 50 Hz Broad Range
P – 100/200 volts, three-phase, 12-lead, 50 Hz Broad Range
R – 231/400 volts, three-phase, 12-lead, 50 Hz Broad Range
S – 277/480 volts, three-phase, six-lead, 50 Hz



2-1
Standby Generator Sets
General Information
Identy003 Rev. 0 11/05
