Generac Portable Products 7,500 EXL Generator
19
Item Part # Qty Description
1 G92432 1 CRADLE
2 G92531 1 SUPPORT, Engine
3 G92731 1 SUPPORT, Engine & Muffler
4 92247 1 HOUSING, Engine Adapter
5 B1342G 1 ASSEMBLY, Rotor
6 B1897G 1 ASSEMBLY, Stator
7 65791 1 BEARING
8 67451 1 WASHER, Special Flat - M8
9 22129 12 WASHER, Lock - M8
10 86307 4 HHMS, 5/16-24 x 3/4 SEMS
11 47481 1 HHCS, 5/16-24 x 10.625
12 92609 2 MOUNT, Vibration
13 82857 4 MOUNT, Vibration
14 40976 2 SCREW, M8 - 1.25 x 20
15 66476 2 CAPSCREW, M6 - 1.0 x 12mm
16 92532 1 BRACKET, Muffler
17 22142 2 SCREW, 5/16 - 18 x 3/4
18 A7433 1 MUFFLER
19 90239 1 GASKET, Muffler
20 81917 1 PIN, Roll 4mm x 10
24 B4986 1 DECAL, Ground
25 66825C 1 CARRIER, Rear Bearing
26 74908 4 TAPTITE, M5-0.8 x 10
27 66449L 4 BOLT, Stator M6-1 x 165mm
28 65795 2 RECTIFIER, Battery Charge
29 66849C 1 TAPTITE, M5-0.8 x 30
30 67022 1 GROMMET, Rubber
31 84132 1 ASSEMBLY, Power Regulator
32 66386 1 ASSEMBLY, Brush Holder
33 66849 2 TAPTITE, M5-0.8 x 16
34 B4871 1 COVER, Bearing Carrier
35 22769 1 WASHER, Shakeproof Int. #10
36 86494 1 SCREW, M6-1.0 x 16 Wing
37 86292 9 HHCS, - #10 Self Driller
38 77395 4 NUT, Flange Lock - M6
39 83465 4 GROMMET, Tank
40 57058 4 HHMS, M6-1.0 x 55
41 80270 1 VALVE, Tank
42 78299 1 BUSHING, Plastic Tank
43 B4363 1 CAP, with Gauge, Fuel
44 B1695 1 TANK, Fuel 7 Gal.
45 B92039 1 SHIELD, Heat
46 92665 1 INSULATION, #2-1/4" Thick
Item Part # Qty Description
47 85000 1 CLIP, Insulation
48 14353621 1 WIRE, Gound
49 26850 2 LW, EXT, Shakeproof M6
51 92982 1 DECAL, Danger
52 B4367 2 DECAL, Heat Shield
55 25244 12 NUT, 5/16-18 Hex
57 B4368 1 DECAL, Control Panel
58 B4366A 1 ASSEMBLY, Control Box
59 NSP 1 ENGINE
60 22531 2 HHCS, 5/16-18 x 1-3/4"
62 93826 1 DECAL, Start Instructions
63 B96068 1 SHIELD, Heat
64 56893 5 CRIMPTITE, 10-24 x 1/2
65 77282 1 SWITCH, Starter
66 22287 2 SCREW, 1/4 - 20 x 3/4
67 22097 2 LOCKWASHER, M6
68 22127 2 NUT, 1/4 - 20 Hex
69 78289 1 BRACKET, Starter Switch
70 22473 4 WASHER, M6 Flat
71 83083 1 SCREEN, Spark Arrester
72 96113 1 ASSY., Wire Starter
Items Not Illustrated
65787 1 Battery Charge Cable
B4369 1 Generator Owner’s Manual
A8927 1 Engine Owner’s Manual
BB3061 2 Oil, 28 oz.
96113 1 Wire, Assembly Starter
22129 2 Lockwasher M8
22145 2 Flatwasher M8
45771 2 Hex Nut M8-1.25
96925 1 Battery Tiedown
96924 2 J-Bolt M8-1.25
96923 1 Battery Tray
15453621 1 Battery Cable Positive
15553621 1 Battery Cable Negative
37806 1 120 Volt 30 Amp Locking Plug
43438 1 120/240 Volt 30 Amp Locking
Plug
Optional Accessories Not Included
84883 Cord Wrap
43630 120/240 Volt 50 Amp Plug
PARTS LIST – MAIN UNIT
