Section 1 — General Information

Air-cooled Generators

1.5 SPECIFICATIONS

1.5.1 GENERATOR

Model 7 kW 10 kW 13 kW 16 kW 18 kW

Rated Max. Continuous Power

Capacity (Watts*)

7,000 NG

6,000 LP

9,000 NG

10,000 LP

13,000 NG

13,000 LP

15,000 NG

16,000 LP

16,000 NG

18,000 LP

Rated Voltage 120/240

Rated Max. Continuous Load Current (Amps)

120 Volts** (NG/LP) 50.0/58.3 75.0/83.3 108.3/108.3 125/133.3 133.3/150

240 Volts (NG/LP) 25.0/29.2 37.5/41.7 54.1/54.1 62.5/66.6 66.6/75

Main Line Circuit Breaker 30 Amp 45 Amp 55 Amp 65 Amp 80 Amp

Circuits***

50A, 240V

---1-

40A, 240V - - 1 1 -

30A, 240V 1 1 1 - -

20A, 240V - 1 - 1 -

20A, 120V 1 3 3 5 -

15A, 120V 5 3 5 5 -

Phase 1

Number or Rotor Poles 2

Rated AC Frequency 60 Hz

Power Factor 1

Battery Requirement Group 26, 12 Volts and 350

Cold-cranking Amperes Minimum

Group 26, 12 Volts and 525

Cold-cranking Amperes Minimum

Weight (unit only in pounds) 336 375 425.5 445/414 421

Enclosure Steel Steel/Aluminum Aluminum

Normal Operating Range -20°F (-28.8°C) to 104°F (40°C) -20°F (-28.8°C) to

77°F (25°C)

* Maximum wattage and current are subject to and limited by such factors as fuel Btu content, ambient temperature, altitude, engine power and condition, etc. Maximum power decreases about 3.5 per-

cent for each 1,000 feet above sea level; and also will decrease about 1 percent for each 6° C (10° F) above 16° C (60° F) ambient temperature.

** Load current values shown for 120 volts are maximum TOTAL values for two separate circuits. The maximum current in each circuit must not exceed the value stated for 240 volts.

*** Circuits to be moved must be protected by same size breaker. For example, a 15 amp circuit in main panel must be a 15 amp circuit in transfer switch.

1.5.2 ENGINE

Model 7 kW 10 kW 13/16/18 kW

Type of Engine GH-410 GT-530 GT-990

Number of Cylinders 1 2 2

Rated Horsepower @3,600 rpm 14.8 18 27 (13kW) / 30 (16kW) / 31.5 (18kW)

Displacement 410cc 530cc 992cc

Cylinder Block Aluminum w/Cast Iron Sleeve

Valve Arrangement Overhead Valves

Ignition System Solid-state w/Magneto

Recommended Spark Plug RC14YC BPR6HS RC14YC

Spark Plug Gap 0.76 mm (0.030 inch) 0.76 mm (0.030 inch) 1.02 mm (0.040 inch)

Compression Ratio 8.6:1 9.5:1 9.5:1
