12 Owner’s Manual for Mobile Generator
General Information
Unit Dimensions
Figure 2-1. Unit Dimensions
Weight
Skid Mounted—Dry lb (kg) 2,010 (911) 2,081 (944) 2,051 (930)
Skid Mounted—Operating lb (kg) 2,450 (1,111) 2,521 (1,143) 2,491 (1,130)
Trailer Mounted—Dry lb (kg) 2,247 (1,019) 2,318 (1,051) 2,288 (1,038)
Trailer Mounted—Operating lb (kg) 2,771 (1,256) 2,842 (1,289) 2,812 (1,275)
Specifications are subject to change without notice.
*Power rating achieved through use of optional 4-position phase switch.
Description UOM MDG25IF4
With SUPERSTART
®
With VFLEX
L W H
Skid Mounted 76 in (1.93 m) 36.37 in (0.92 m) 53.5 in (1.35 m)
Trailer Mounted 139.25 in (3.53 m) 51.75 in (1.31 m) 64.75 in (1.64 m)
011143
L
H
W
L
H
W
