Electrical Connections
22 Installation Manual for Generac PWRCell Inverter
Table 5-11. Automatic Detection Troubleshooting Table
Event Name Event Code Description Possible Solution
ct cal = 1 0x8061 Line 1 doesn’t have a valid CT calibration Check wiring and CT integrity
ct cal = 2 0x8062 Line 2 doesn’t have a valid CT calibration Check wiring and CT integrity
ct cal = 3 0x8063 Line 1 & 2 don’t have a valid CT calibration Check wiring and CT integrity
ct cal = 4 0x8064 Line 3 doesn’t have a valid CT calibration Check wiring and CT integrity
ct cal = 5 0x8065 Line 1 & 3 don’t have a valid CT calibration Check wiring and CT integrity
ct cal = 6 0x8066 Line 2 & 3 don’t have a valid CT calibration Check wiring and CT integrity
ct cal = 7 0x8067 Line 1 & 2 & 3 don’t have a valid CT calibration Check wiring and CT integrity
ct cal = 9 0x8069
Line 1 has multiple CTs on it (or a CT is on the
neutral wire)
Check wiring and CT integrity
ct cal = A 0x806A
Line 2 has multiple CTs on it (or a CT is on the
neutral wire)
Check wiring and CT integrity
ct cal = B 0x806B
Lines 1 and 2 have multiple or missing CTs on
them (or a CT is on the neutral wire)
Check wiring and CT integrity
ct cal = C 0x806C
Line 3 has multiple CTs on it (or a CT is on the
neutral wire)
Check wiring and CT integrity
ct cal = D 0x806D
Lines 1 & 3 have multiple or missing CTs on them
(or a CT is on the neutral wire)
Check wiring and CT integrity
ct cal = E 0x806E
Lines 2 & 3 have multiple or missing CTs on them
(or a CT is on the neutral wire)
Check wiring and CT integrity
ct cal = F 0x806F
Lines 1 & 2 & 3 have multiple or missing CTs on
them (or a CT is on the neutral wire)
Check wiring and CT integrity
ct cal success 0x8070 Calibration was successful Check wiring and CT integrity
