Commissioning and Setup
Installation Manual for Generac PWRCell Inverter 31
Enabling Beacon TOU
Once the TOU Schedule is set, the scheduler will auto-
matically enable itself and begin running. However, if the
scheduler becomes disabled for any reason, follow the
instructions below to re-enable the scheduler:
1. See Figure 6-19. Navigate to the Beacon device
page and press the center button to enter the
device menu.
Figure 6-19. Enabling Beacon (1 of 2)
2. Highlight Enable and press the center button.
3. See Figure 6-20. Arrow sideways to Confirm and
press the center button.
Figure 6-20. Enabling Beacon (2 of 2)
Disabling Beacon TOU
The scheduler can be disabled at any time. To disable
the scheduler:
1. See Figure 6-21. Navigate to the Beacon device
page and press the center button to enter the
device menu.
Figure 6-21. Disabling Beacon (1 of 3)
2. Highlight Disable and press the center button.
3. See Figure 6-22. Arrow sideways to Confirm and
press the center button.
Figure 6-22. Disabling Beacon (2 of 3)
4. See Figure 6-23. The status line on the Beacon
device page will read Disabled.
NOTE: The system will remain in the current system
mode until the mode is changed manually or the sched-
uler is re-enabled.
Figure 6-23. Disabling Beacon (3 of 3)
Temporarily Overriding the TOU Scheduler
The scheduler can be temporarily overridden at any time
without disabling it. The manual override will apply until
the next regularly scheduled system mode change.
To temporarily override the scheduler:
1. Navigate to the system home page.
2. Press the center button.
3. Select the desired temporary system mode.
NOTE: See the Generac PWRcell Inverter Owner’s
Manual for more information on system modes.
When the scheduler has been overridden:
• Temporary Override will display on the home page,
alternating with the words Scheduler Active and
the name of the current system mode.
• See Figure 6-24. Running, Overridden will display
on the Beacon device page.
