General Dynamics Itronix GoBook VR-2 - IDE Configuration

IDE Configuration
CAUTION
Changes to the Primary Master setup may render the Hard Disk Drive unusable and result in data loss.
Serial Port A
Enabled
Disabled
User can configure this serial port when set
to enabled.
Base I/O address: 2E8
2F8
3E8
3F8
Sets the base I/O address for this serial port.
Interrupt: IRQ3
IRQ4
Sets the interrupt request of this serial port.
Serial Port B
Enabled
Disabled
User can configure this serial port when set
to enabled..
Base I/O address: 2E8
2F8
3E8
3F8
Sets the base I/O address for this serial port.
Interrupt:
IRQ3
IRQ4
Sets the interrupt request of this serial port.
Parallel
Port:
Enabled
Disabled
User can configure this parallel Port when set
to enabled.
Field Setting Function
