General AUG18UBAB AOG18UNCNL

(unit : mm)
INDOOR UNIT
OUTLINE AND DIMENSIONS
650
650
22006.03.23
20
235
66
250
440
580
( 650) (Grille measurement)
650
(Hanging bolt position)
400
(Hanging bolt position)
606
580 66
440
35
600
(Ceiling opening measurement)
250
60
86
Drain pipe (I.D. 32)
54
46
131 111
47
