Models :
AUG18FBAB / AOG18FNCKL
AUG18FBAB / AOG18FNCNL
Models :
AUG18UBAB / AOG18UNCKL
AUG18UBAB / AOG18UNCNL
Refrigerant pipe
12.7mm(1/2")
Refrigerant pipe
6.35mm(1/4")
Charging valve
OUTDOOR UNITINDOOR UNIT
Evaporator
Evaporator
OUTDOOR UNIT
12.7mm(1/2")
6.35mm(1/4")
Charging valve
INDOOR UNIT
REFRIGERANT SYSTEM DIAGRAM
Capillary tube
Compressor
Strainer
Condenser
4-Way
valve
Compressor
Condenser
Distributor
Muffler
Refrigerant pipe
Refrigerant pipe
Capillary tube
Strainer
Strainer
42006.03.23
