Triple readout LCD. In normal display mode, upper readout shows total
(triaxial) EMF intensity and lower readouts show current day and hour and
current minute and second. In alternate display mode, upper readout
shows field intensity on x axis and lower readouts show field intensity on y
and z axes.
(Power) button. Press and hold for at least 3 seconds to power meter
on and off.
button. “Freezes” displayed EMF reading(s). Also used to disable Auto
Power Off (APO) function.
MX/MN button. Used to show highest (maximum) and lowest (minimum)
value of triaxial EMF intensity measured since meter was last powered on.
G/T button. Toggles between microTeslas (μT) and milliGauss (mG) units of
EMF intensity.
Range button. Used to exit Autoranging mode and select one of three
available manual ranges.
SET button. Toggles between normal and alternate display modes. Also
used to set data logging sampling time as well as currrent day and time.
