Page #12 background imageLoading...
Page #12 background image
You can now use the software to “configure” your HT20.
Configuring the device means choosing four key parameters:
Sampling time—How often it makes and stores
humidity and temperature measurements.
Temperature unit—degrees Fahrenheit or Celsius
(°F or °C).
High and low temperature alarm setpoints
High and low humidity alarm setpoints
To begin, click on “Set up the USB Data Logger” in the
window shown in the figure above. Doing so will cause the
following window to appear.
Using your mouse, trackball or touchpad, first choose your
Temp Scale and Sample Rate (sampling time). With regard to
sampling time, using the shortest setting of 10 seconds may
result in too much essentially identical data being stored in
12
Device HT20 is connected!
Fig. 3. The HT20 configuration (Setup) window
! " # $ % & ' % ( ) * + , - . / 0 1 2 / " 3 4 5 4 ! 4 / % 6 7 3 8 4 5 8 4 ! 9 : " ! ; $ ; % < = 4 !
