CLEANING …. continued
4.
Place the knife over the feedscrew stud, being sure that the
square opening in the knife is fully seated in the feedscrew stud.
NOTE: The sharp edge of the knife MUST FACE OUTWARD.
5.
Place the cutter plate onto the feedscrew stud in front of the
knife, being sure the groove in the plate fits over the pin in the
cylinder head.
6.
Place the ring collar on the cylinder head, tightening it by turning
NOTE: Do not overtighten the ring collar. Binding or excessive wear to
the internal parts will occur if the ring collar is too tight.
7.
Place the tray on the tray support bracket with the spout seated
in the cylinder head.
7
