REPLACEMENT PARTS
MODEL: ASM—HD
KEY
NO.
PART NO.
QTY
PER
NAME/DESCRIPTION MACH.
KEY
NO.
PART NO.
NAME/DESCRIPTION
QTY
PER
MACH.
300 1-SM-1593 Base (ASM-HD) 1
340 8-SM-1742 Lockwasher: Gearbox 4
301 1-SM-1569 Carriage: Platform 1
Mounting
302
1-SM-1603
Support: Oscillation Arm
1
303 8-SM-1594 Lever, Engagement 1
341 8-SM-1743 Nut: Gearbox Mounting 4
304 4-SM-1600 Oscillation Arm 1
342 8-SM-1592 Screw: Gearbox Mounting 4
305 9-SM-1709 Food Pusher W/spikes 1
343 5-SM-1708 Brush Assy.: DC Motor 2
(ASM-HD)
344
9-SM-1744
Cap: DC Motor Brush
2
306
9-SM-1638
Knob: Lift Lever
1
345
8-SM-1604
Set Screw: Oscillation
1
307 6-SM-1695 Foot (ASM-HD) 4
Arm Support
308 8-SM-1582 Retaining Ring: 2
346 8-SM-1647 Screw: Bearing Retainer 2
Connecting Arm
347 8-SM-1598 Screw: Roller Bushing 1
309 8-SM-1609 Key: Pivot Arm Assy. 1
Spindle
310 8-SM-1584 Bearing: Oscillation Arm 1
348 8-SM-1597 Washer: Rlr Bush. 1/4
311 8-SM-1586 Bushing: Pivot Arm 2
SpdI/Btm Cvr.
312 4-SM-1623 Bottom Cover 1
349 8-SM-1595 Set Screw: Engage.Lever 1
313 2-SM-1606 Motor (D.C.) 1
350 8-SM-1571 Screw: Carriage 2
30-SM-1606 Gear Motor Assy. 1
351 8-SM-1577 Screw: Oscillation Arm 1
(Inc. 314)
Roller Bush.
314 9-SM-1589 Gear Box Assembly 1
352 8-SM-1599 Set Screw: Oscillation Arm 2
315 9-SM-1574 Spring: Oscillation Arm 1
353 8-SM-1745 Jam Nut: Oscillation Arm 2
316 9-SM-1736 Spring: Lift Lev. Rel. Pin 1
Set Screw
317 9-SM-1570 Spring: Carriage 2
357 30-MM-2085 Speed Control: D.C. Motor 1
318 8-SM-1657 Stud: Oscillation Arm 2
358 8-SM-1655 Nut: Osc. Arm Sup/ 2/2
Support
Clamp BIk
319 9-SM-1632 Roller: Lift Lever 1
359 8-SM-1431 Washer: Clamp Block 2
320 8-SM-1585 Screw: Oscillation Arm 1
360 8-SM-1583 Washer: Connecting Arm 2
321 8-SM-1607 Pivot Pin: Connecting Arm 1
362 8-SM-1596 Engagement Bracket 1
322
8-SM-1573
Bushing: Oscillation Arm
1
363
30-MM-2086
Potentiometer W/Wires
1
323 8-SM-1572 Engagement Cam Pin * 1
364 9-SM-1616 Label: Control 1
324 9-SM-1575 Spindle: Roller Bushing 1
365 5-6-1626 Circuit Breaker 1
325 9-SM-1576 Roller Bushing: 1
366 5-MM-2060 Knob: Speed Control 1
Oscillation Arm
368
8-SM-1276
Nut: Housing Assy. Stud
4
326 4-SM-1587 Pivot Arm Assy. 1
369 8-SM-1640 Screw: Bottom Cover 4
327 4-SM-1580 Connecting Arm 1
370 8-SM-1635 Stop Pin: Lift Lever 1
328 8-SM-1737 Key: D.C. Motor 1
371 8-SM-1637 Screw: Lift Lev. Clamp BIk 2
329
4-SM-1658
Cover Plate: Oscillation
1
372
8-SM-1633
Pin: Lift Lvr Rlr/
2/1
Arm Sup.
Engage.Lvr
330
9-SM-1707
Lift Lever
1
377
8-SM-1659
Screw: Oscillation Arm
2
331 8-SM-1651 Spacer: Osc. Arm 2
Support
Support
378
8-SM-1652
Washer: Oscillation
2
332 8-SM-1634 Clamp Block: Lift Lever 1
Arm Sup Screw
333-
8-SM-1648 Bearing Retainer 1
379 8-SM-1591 Screw: Pivot Arm Assy. 1
334 8-SM-1605 Stud: Housing Assembly 4
380 8-SM-1590 Washer: Pivot Arm Assy. 1
335 8-SM-1739 Release Pin: Lift Lever 1
381 8-SM-1076 Slide Screw: Carriage 1
336
9-SM-1740
Knob: Lift Lev. Rel. Pin
1
337 8-SM-1578 Spacer: Connecting Arm 2
338
8-SM-1738
Screw: DC Motor
4
Mounting
339
8-SM-1741
Washer: Gearbox
4
Mounting
GENERAL SLICING/RED GOAT DISPOSERS
