FOOD FENCE REMOVAL
1. Loosen lock knob (counter-clockwise.) (Fig. 7)
2. Slide fence off of platform. (Fig. 7)
PLATFORM REMOVAL
1. Unscrew (counter-clockwise) and remove platform knob. (Fig 81)
2. Pull platform assembly straight out and off of slicer. (Fig. 9)
KNIFEWIPER REMOVAL
NOTE: The knifewiper is located at the lower back side of knife in the
receiving area.
1. Unscrew and remove thumbscrew (counter-clockwise) (Fig. 10)
2. Remove knifewiper by pulling straight out.
4
