13
Elite Steam +03U221903 REV 2.1
≥15°
≥5°
1,5 m (5 FTmax.)
IF NO
TRAP
≥15° ≥15°
≥5°
1,5 m (5 FT max.)
3 m (10 FT max.)
DNEB ELTNEG
OBSTUCTION
SUPPORTED STEAM HOSE
AND/OR COPPER PIPE
NO SLOPE
KINKED
≥5°
3 m (10 FT max.)
PART HTIW
DR AINS
DRAINS
YES
NO
DRAINS
THAN THE DUCTS STATIC PRESSURE
≥15°
1,5 m (5 FTmax.)
IF NO EPO LS
0,9 m (3 FTmax.)
Fig. 3.m
Fig. 3.n
≥20°
A
C
B
IMPORTANT: Maximum length of rubber steam hose is 4m (12 feet.). Insulated copper tubing may be up to 6m(20feet) in length.
-2 esU .swoble dna sdneb prahs eziminim ,sesac lla nI
45° elbows instead of
90°s.
Hose inner diameter = 7/8”
( 22 mm).
Hose outer diameter = 1-1/4” (30 mm).
3.4.4 Remote Mount Blower
Remote Mount Blowers, are used to distribute the steam directly into the room. The drawings show the minimum
recommended distances to avoid the flow of humidified air from coming into direct contact with persons, lights,
electrical appliances, and surfaces before the steam has been totally absorbed by the environment.
For further details on the assembly, the electrical connections and the use of a Remote Mount Blower,
please refer to the specific instruction manual.
Millimeters
Inch
A
150 mm
6 “
B
1800 mm 72 “
C
600 mm 24 “
D
2100mm 84 “
Tab. 3.g
P- TRAP
NOTE: HEIGHT OF TRAPS MUST BR GREATER
NOTE
• SLOPE PIPING UP IN DIRECTIONS OF STEAM FLOW AT 20% OR GREATER, WHICH MEANS 63.5MM (2 1/2” PER FOOT)
• SLOPE PIPING DOWN IN THE DIRECTION OF STEAM FLOW AT 5% OR GREATER, WHICH MEANS 19MM (2 1/2” PER FOOT).
• MAX. LENGTH OF RUBBER STEAM HOSE IS 4M(12 FT).
• HEIGHT OF P-TRAPS MUST BE GREATER THAN THE DUCTS STATIC PRESSURE.
D
TYPICAL INSTALLATION
WHEN THE UNIT IS ABOVE
THE DISTRIBUTOR PIPE
SAG
NO SLOPE
NO TRAP
UNDRAINED
ELBOW
UNDRAINED
ELBOW
NO DISTRIBUTION
PIPE DRAIN
