4 Checks prior to operation:
4.1 Battery connection (only electrical models with electrical startup).
Before charging the electrolyte and
connecting the battery, check that the
engine switch is in the "OFF" or "0"
position.
If you have any questions on
identifying the engine switch, check
chapter
3.1 CONTROL PANEL.
Loosen the support fastening bolts for
the battery, extract it and place it on a
leveled and secure surface.
FASTENING BOLTS
BATTERY
MODEL FORMIGAL 6.0kW (7.5kVA)
AC400V 16AH OUTLET
AC400V OVERLOAD PROTECTOR
GROUNDING
AC230V 16AH OUTLET
V-HZ-H DISPLAY INDICATOR
ENGINE SWITCH
AC230V OVERLOAD PROTECTOR
