Genesis GPCS535CK User Manual

English
Plunge Circular Saw with Miter Base
Operator’s Manual GPCS535CK
KNOWING YOUR PLUNGE CIRCULAR SAW AND MITER
BASE
1. Lock-Off / Plunge Release Button
2. ON/OFF Trigger Switch
3. Laser
4. Retractable Lower Blade Guard
5. Saw Blade
6. Base Plate
7. Soft Grip
8. Cutting Depth Clamp
9. Cutting Depth Scale
10. Blade Clamping Screw
11. Rip Guide Locking Screw
12. Allen Key and Holder
13. Laser ON/OFF Switch
14. Spindle Lock
15. Gear Box
16. Dust Extraction Nozzle
17. Guide Rails
18.. Miter Angle Base
19. Miter Fence
20. Fence Locking Lever
21. Miter Angle Scale
22. Tiltable Support
23. Clamp
24. Clamping Knob
25. Fence Extension
26. Miter Base Lock Knob
20
26
19
20
21
23
24
17
22
25
18
FIG 1
1
5
4
3
2
10
11
6
12
9 8
7
13
14
15
16

Genesis GPCS535CK Specifications

General

Brand	Genesis
Model	GPCS535CK
Category	Saw
Language	English
