Genie 2022 User Manual

PN# 37026500123 05/15/2009
FASTENERS -
Shown Full size (
See Parts List below for full description.)
Lag screw - 5/16" x 2"
Self-drilling Screw
1/4 -20 x 3/4"
Hex Flange Nut
1/4 -20
Cotter pin
Clevis pin
5/16" x 3/4"
Hex Bolt - 5/16 -18 x 3/4"
Hex Flange Nut
5/16 -18
Rail Clamp Bolt - 5/16 -18 x 5/8"
#10-16 x 1-1/4" Phillips Hex Screw
Hex Bolt - 5/16 -18 x 1/2"
#4-24 x 1" Pan Head
Phillips Screw
Clevis pin, long 5/16" x 3"
7
BAG NO. DESCRIPTION QUANTITY
0 RAIL SECTION CLAMP 2
RAIL CLAMP BOLT – 5/16 -18 x 5/8'' 8
HEX FLANGE NUT – 5/16 -18 8
1 BOLT – 5/16 -18 x 1/2'' 3
2 CLEVIS PIN, LONG – 5/16" x 3" 1
COTTER PIN 1
HEADER BRACKET 1
LAG SCREW – 5/16'' x 2'' 2
3 HEX BOLT – 5/16 -18 x 3/4'' 5
HEX FLANGE NUT – 5/16 -18 5
LAG SCREW – 5/16'' x 2'' 2
4 SELF DRILLING SCREW – 1/4 -20 x 3/4'' 3
DOOR BRACKET 1
5 HEX BOLT – 5/16 -18 x 3/4'' 3
SELF LOCKING NUT – 5/16 -18 1
HEX FLANGE NUT – 5/16 -18 2
CLEVIS PIN – 5/16" x 3/4" 1
COTTER PIN 1
6 WALL CONTROL ASSEMBLY 1
PAN HEAD PHILLIPS SCREW – #4-24 x 1'' 2
7 13 MM INSULATED STAPLE 30
8 Safe-T-Beam
®
SOURCE/SENSOR BRACKET 2
PHILLIPS HEX SCREW – #10-16 x 1- 1/4'' 4
WIRE NUT (GREY) 4
NO NUMBER
REMOTE WITH BATTERY 1
NO BAG Safe-T-Beam
®
SOURCE/SENSOR & WIRE SET 1
NO NUMBER
LIGHT COVER - WHITE 2
Self Locking Nut
5/16 -18
Wire Nut
MISSING ANY PARTS?
Please call toll free - 1.800.354.3643
DO NOT RETURN TO POINT OF PURCHASE.
IMPORTANT! - Information needed when calling
• Model number - (located on packaging)
• Store, city, state, and date of purchase
Shoulder Bolt
5/16 -18 x 1"

Genie 2022 Specifications

General

Smartphone Control	Yes
Wi-Fi Connectivity	Yes
Motor Type	DC Motor
Model	2022
Type	Garage Door Opener
Drive Type	Belt Drive
Horsepower	1/2 HP
Battery Backup	Yes
Voice Control	Yes (compatible with Alexa, Google Assistant)
Speed	7 inches per second
Remote Control	Yes
Security	Rolling Code Technology
Warranty	Limited Lifetime (Motor), 1-5 Years (Parts, depending on the specific model)
