Genie 2022 User Manual

21
UNLOCK
DOOR
LOCK
TO RECONNECT
PULL TOWARD
DOOR
TO RELEASE
PULL TOWARD
THE OPENER
FIG. 6-3 Engage/Disengage Carriage Lock.
CARRIAGE LOCK
The Carriage Lock can be manually engaged or
disengaged.
• To disengage Carriage Lock
– Pull handle downward opener power head.
• To engage Carriage Lock
– Pull handle towards door.
1. By turning the "Close Force Control" clock-
wise, the DOWN force can be increased. By
turning the "Close Force Control" counter-
clockwise, the DOWN force can be decreased.
Set the DOWN force level at the minimum force
required to close door without reversing.
2. Once the desired level is selected, this stores the
necessary force level for the DOWN direction in memory.
3. By turning the "Open Force Control" clockwise,
the UP force can be increased. By turning the
"Open Force Control" counter-clockwise, the UP
force can be decreased. Set the UP force level at
the minimum force required to open door without
stopping.
4. Once the desired level is selected, this stores
the necessary force level for the UP direction
in memory.
OPEN
CLOSE
OPEN
CLOSE
UP/DOWN FORCE
OPEN
FORCE
CLOSE
Down Force
Control
Adjustment
Up Force
Control
Adjustment
ROTATE
CLOCKWISE
ROTATE
COUNTER-CLOCKWISE
(Increasing Force)
(Decreasing Force)
FIG. 6-4 Force Control Adjustment.

Genie 2022 Specifications

General

Smartphone Control	Yes
Wi-Fi Connectivity	Yes
Motor Type	DC Motor
Model	2022
Type	Garage Door Opener
Drive Type	Belt Drive
Horsepower	1/2 HP
Battery Backup	Yes
Voice Control	Yes (compatible with Alexa, Google Assistant)
Speed	7 inches per second
Remote Control	Yes
Security	Rolling Code Technology
Warranty	Limited Lifetime (Motor), 1-5 Years (Parts, depending on the specific model)
