Genie GCL-GCX Product Guide

www.GenieCompany.com/commercial | 800.843.4084
©2012 The Genie Company | GCL-GCXss
GCL-GCX | LIGHT-DUTY COUNTER DOOR OPERATOR
*Under-balancedreshuttershaveamaxsquarefootageof52squarefeetfor22gaugesteeland42squarefeetfor20gaugesteel.Notes:
Accessories and Options
• HandCrank
Allowsforopening/closingviahandcrank.Optiononlyavailableon
counter-doormodels.
• TimertoCloseModule
**

TimedclosesetviatheLCDdisplayfrom2secondsupto5minutes.Includes
pre-closewarningcontacts,timerholdinput,auxiliaryopeninput,normally
closedsafetyinput,andmonitorededgeinput.
• AuxiliaryOutputModule(standardonredoorversion)
Providesrelaycontactsattheopen,close,andmid-stoplimits.Contacts
for5-minutelamp,and“ADA”contactssetviaLCDdisplaytowarnduring
opening,closingorboth.
• UL325-2010ApprovedReversingDevices
Theinstallationofamonitoredexternalentrapmentdeviceisrequiredfor
momentarycontactcloseoperationonallcommercialdooroperators.Only
thefollowingdevices,whenpurchasedthroughGenie,areUL-approved
forusetomeetthisrequirement:
• Safe-T-Beam
®
PhotoeyeKitwithadjustablebracketP/N38176R.S
1
• Impact-protectedCommercialPhotoeyeKitP/NOPAKPE.S
• MillerEdgeME/MT/CPT(DCorT3)2-wireedgesensor.Must
beusedwithTCM(OPABTCGX.S**)orInterfaceModule
(OPAKMEIGX.S).
• Nema4PhotoeyesP/NOPAKPEN4GX.S
1
— Default device when operator is ordered.
**— Not available on fire-door version.
Construction
• Motor
1/2HP,ACcapacitorstart/runmotor.Motorreplaceablewithout
changinglimits.
• Drive
Primaryreductioniswormgear.Secondaryreductionisbyhardened
bevelgear.Powertrainincorporatesoil-impregnatedbushings.
• Governor(FireDoorVersionOnly)
Includedonredooroperatorversion.Controlsthedescenttodoor
inanon-poweredalarm/testdrop.
• EmergencyManualOperation
Pullcorddisconnectdisengagesdriveallowingdoortobemoved
manuallywhilemaintaininglimits.
• Pre-wiredtoaccept:
-Monitoredentrapmentdevicesuchasphotoeyes.
-Singleor3-buttoncontrolstations.
-Externalinterlockswitches.
MAX DOOR SIZE (SQ*FT) - ROLLING
Door Series
SteelNon-Insulated SteelInsulated CounterDoors Grilles
FireStar2”
Slat
FireStar3”
Slat
Model
Max
Door Wt.
(lbs.)
16GA. 18GA. 20GA. 22GA. 24GA. 26GA. 18GA. 20GA. 22GA. Aluminum STL/SST Aluminum STL/SST 20GA. 22GA. 16-22GA.
GCX
500
N/A N/A 144 144 144 144 N/A N/A N/A 126* 126* 142 108 82 94 N/A
AMPERAGE RATING - 60Hz
HP 115V 1Ø
1/2 6.0
Dealer Imprint Area
