Genie GS-1330m User Manual

Operator's Manual First Edition • Second Printing
Controls
24 GS
™
-1330m Part No. 1290846GT
Platform Control Panel
1 Red Emergency Stop button
Push in the red Emergency Stop button to the
off position to stop all functions. Pull out the
red Emergency Stop button to the on position
to operate the machine.
2 Lift function button
Push this button to activate the lift
function.
3 Horn button
Press the horn button and the horn
will sound. Release the horn button
and the horn will not sound.
4 Drive speed select button
Press this button to activate the
slow drive function. The indicator
light will be on when slow drive is
selected.
137636
STOP
+
-
=
1
5
3
6
4
2
8
7

Genie GS-1330m Specifications

General

Brand	Genie
Model	GS-1330m
Category	Scissor Lifts
Language	English
