Operator's Manual Supplement First Edition • Third Printing
Introduction
6 Panel Cradle Part No. 82518GT
Install the Strap:
13 Install clamp (Genie part number 56424GT)
around the vertical platform rail tube. Refer to
Illustration 2.
14 Secure the strap assembly (Genie part
number 77664GT) to the clamp with retaining
fasteners (Genie part numbers 1256855GT
and 1277924GT). Do not over tighten.
Note: The strap assembly should be secured
between the clamp.
Note: The strap assembly should be able to slide
freely up and down the platform rail.
Operating Instructions:
1 Secure both panel cradles to the platform.
2 Place the load so that it rests in both panel
cradles.
3 Center the load on the platform.
4 Secure the load to the platform using the
strap.
5 Tighten the strap.
Panel Cradle Part No. 82518GT Operator's Manual Supplement First Edition • Third Printing
