Genius GHT-511 - Chapter 6. Parts List (Venders Number)

Service Manual
Chapter 6. Parts list (Vender’s number)
Item Part number description Position
1 J66-01236-000 PCBA AMP
2 J66-01236-400 PCBA CENTER AMP
3 J66-01335-000 PCBA POWER
4 J66-01335-010 PCBA VOLUME CONTROL
5 J83-005AA-U00 FUSE 125V/5A SLOW BLOW
6
J51-00002-03 NJM4558DD
7
J53-00001-02 Diode 1N4148
8
J51-01054-000 IC TDA7296 60W
9
J52-21001-000 Resonator 4MHZ
10
J51-01011-000 IC TL074/
11
J51-11018-000 IC L7815
12
J51-11019-000 IC L7915
13
J51-21006-010 IC PT2258
14
J52-00027-01 Transistor 2SC1815
15
J52-31003-000 FET 2SJ111
16
J53-21009-000 Diode KBU808
17
J51-11024-000 IC L7805CV/ST
18
J51-21002-300 MPU EM78P451P
19
J52-00026-02 Transistor 2SA1015
