2.8 Install the Acrylic Baffles
What you will need
3mm
41 48 5
right baffle first, by placing the baffle along
side the frame to fit the shape. Peel off the
Step 1: Insert the M5 bolts from the outside
baffle, the M5 bolt should insert from the left
from the other side using your hand. One
the T-Slot nuts horizontally.
Step 2: Place T-Slot nuts into the side of the
machine so that the baffle is aligned with the
edge of the frame.
