Genmitsu 3018-PROVer - 3.1 Install the Main Control Board

24
3.1 Install the Main Control Board
What you will need
746 47
Step 1:
on the control board. Put on the M3 T-Slot nuts trough
nut loose and in horizontal position so that they can
Step 2: Position the frame so that the back of the machine is
nuts onto the top and bottom beams on the frame, like shown
in the figure below.
