Genmitsu 4040-PRO MAX - Page 13

11
Y-axis Slider
Y-axis Slider
Y-axis Module (Left)
Y-axis Module (Left)
Mechanical Installation
1. Turn the handwheels on the YL&YR modules clockwise so that the Y-axis sliders on the module fit exactly against the rear mounts.
STEP 4 Installing X-Axis Assemblies
Rear Mount
Rear Mount
Handwheel
