Gentex NVS - Kit Contents; Tools Required; Installation Instructions

Page 1 of 11 Revision A 550-0426
KIT CONTENTS:
Item
Qty
Part Number
Description
1
1:
ADVGEN20A
7 Pin Auto-Dimming Mirror with Compass and Temperature
2
1
Contact VOXX
Customer
Service
Installation Parts Pack
7 Pin Harness Assembly with 2 Wires (Ignition and Ground)
3
2
--
T-Tap Connectors (1 Red 18 – 22 AWG, 1 Blue 14 – 18 AWG)
4
5
--
Short Tie Wraps
Not shown
1
--
Installation Instructions
Not shown
1
--
User Guide
Not shown
1
--
Warranty Card
* Mirrors Equipped with Temperature Feature:
5
1
--
Temperature Sensor
6
1
--
Temperature Sensor Harness (7 Pin Applications)
7
5
--
Long Tie Wraps
* Optional Items (Not Included with Installation Kit)
8
1
--
Wire Cover
TOOLS REQUIRED:
Safety Glasses
Utility Knife
Pliers
#2 Phillip's Screwdriver
Clean Rag
Electrical Tape
4mm Flat Screwdriver
Flashlight
DC Voltmeter
Fish-Wire (Coat Hanger)
#T20 Torx Driver
Panel Removal Tool
Gentex by VOXX Corporation
Installation Instructions
