• Coupled Transients (Electrical Fast Transients, Chattering Relay)
• Electrostatic Discharge (ESD)
• Electromagnetic Compatibility (EMC)
• Electromagnetic Interference (EMI)
Accelerometer &
gyroscope
3D accelerometer and 3D gyroscope. Full-scale acceleration range of ±8 g and an angular rate
range of ±250 dps.
Acceleration and angular rate output data rate of 1.66 kHz.
Mechanical
Weight: 97 g (0.21 lbs)
Dimensions: 77.3 mm L × 53 mm W × 27.5 mm H
Housing: PC + ABS - SABIC CY6414 (Flame retardant)
Electrical
Voltage: 12 V and 24 V systems supported
Tracking mode (ignition on)
Wi-Fi off
• Peak power: 320 mA @ 12 V, or 3.84 W
184 mA @ 24 V, or 4.416 W
• Average power: 96.2 mA @ 12 V, or 1.15 W
55.1 mA @ 24 V, or 1.322 W
Wi-Fi on
• Peak power: 433 mA @ 12 V, or 5.196 W (Tx power is 23 dBm)
249 mA @ 24 V, or 5.975 W
• Average power: 330 mA @ 12 V, or 3.96 W (Tx power is 10 dBm)
189.7 mA @ 24 V, or 4.554 W
IOX Operating Mode
• Up to 2 A Current
• Resettable overcurrent protection to IOX
Compliance
FCC, ISED, PTCRB, NOM, CE, RoHS, REACH, WEEE, UKCA, E-Mark
Carriers: AT&T, TELUS, Rogers
Over-the-air (OTA)
support
Firmware Updates: For maintenance, new features, and custom applications
Parameters: For turning additional features on/off
Almanac/Ephemeris Data: For quicker GPS latch
In-cab buzzer
Decibel Output: >80 dBA at 10 cm
Driver Feedback: Harsh braking, harsh acceleration, harsh corners, over-revving, excessive idling
and speeding, engine based seatbelt violations (when available), and custom
