GeoVision GV-FD2410 User Manual

Bullet Camera
9
9.4 Installation
These instructions describe the basic installation of the Bullet Camera.
1. Slide the cable clamp to the camera base.
Cable Clamp
Figure 9-2
2. Install the Bullet Camera to the wall.
Figure 9-3
3. Remove the protection sticker from the camera’s cover
4. Connect the power, network and other wires to the Bullet Camera.
See 9.4.1 Connecting the Camera.
111

GeoVision GV-FD2410 Specifications

General

Camera Type	Dome
Lens Type	Fixed
Focal Length	3.6 mm
Aperture	F2.0
Ethernet	10/100 Mbps
Network Interface	RJ-45
Ingress Protection	IP67
Minimum Illumination	0 Lux (IR on)
IR LED Quantity	12
Day/Night	ICR
Video Compression	H.264
Max. Frame Rate	30 fps
Audio Support	No
Protocols	HTTP, TCP/IP, UDP, RTSP, RTP, SMTP, FTP, DHCP, DNS, DDNS, NTP, UPnP
Power Supply	12V DC
