German pool GPU Series - 產品結構 Product Structure

P.12
GPU-6.5SSJ-JF
產品結構 Product Structure
防倒流裝置
出水位 (熱)
入水位 (冷)
溫度調節/超溫斷路器
排水管
超溫及超壓排放閥
1
2
3
4
5
6
1
1
5
3
3
5
2
6
4
4
2
5
6
GPU-6.5SSJ-JB
Anti Back Siphonage Device
Outlet (Hot)
Inlet (Cold)
Combined Thermostat / Cutout
Drain
Pressure & Temperature Relief Valve (PTV)
1
2
3
4
5
6
