P.8
安裝說明 Installation Instructions
接電方法
由電箱獨立伸延一條適合之電線（見下表）至浴
室門外接駁獨立開關掣，再將電線伸延至熱水器
穿進灰色線夾接到電線排上分別接上零線（N），
火線（L），及地線 等。
本熱水器必須永久可靠地連接地線。
Electric Wiring
Use an independent wire (refer to table below)
leading from the meter box and connect it to an
independent on/off switch outside bathroom.
Extend the wire through the grey wire grip on the
water heater. Dismount the bottom plate and wire
up Neutral (N), Life (L) and Earth terminals.
This water heater must be earthed at
all time.
發熱線功率 (千瓦)
Heating Element Rating (kW)
所需電源(安培)
Electric Current (A)
電源線最低要求(平方毫米)
Wiring (mm²)
3kW 15 A (單相1PE) 2.5 mm²
電源開關
設於熱水器外用以切斷電源供應之開關掣，應全
極切斷電源，兩極之間應保持最少3mm距離。
測試使用
水喉與電源接駁妥當及內膽注滿水後，便可進行
通電。此時指示燈會亮著，用戶便可將自動恒溫
旋鈕調校至最高度數。當溫度達到75°C時，恒溫
器即會自動停止加熱。選擇適當溫度後不應以恒
溫旋鈕當作開關掣使用，因此舉會縮減該配件之
使用壽命。
Power Switch
The external switch is used to completely
disconnect water heater from power supply.
It should disconnect all poles, and a contract
separation of at least 3mm must be present.
Testing
When the piping and wiring are connected and
inner tank has been lled with water, switch on the
power. The indicator on the water heater will be lit.
Turn control knob to the desired temperature (Max.
temperature is 75°C). Do not use the control knob
as an on/off switch.
!
警告！
本熱水器必須永久可靠地連接至水
管，且不能使用軟管連接。
!
WARNING!
The water heater must be
permanently and reliably connected
to the water pipe and must not be
connected with a hose.
