P.12
E. Connect Exhaust Hose To Window Adaptor Kit
1. Close the window till it ts snugly against the window adaptor kit. If necessary, secure the window
kit with duct tape.
2. Lock the exhaust hose adaptor onto the opening in the window adaptor kit.
Note:
Place this product close to the window when connecting the exhaust hose. After exhaust hose is
connected, move this product away from the window, and keep at least 20 inches (approx. 50cm)
empty space between this product and any surrounding wall or object.
• DO NOT allow the exhaust hose to bend or ex more than 45° in order to keep good ventilation of
exhaust hose.
• Make sure exhaust hose has been properly installed on both ends before using this product.
Installation Instructions
5. Slide the extension panel between the main panel and the screw’s 2.5mm gap and adjust the
length needed to cover the window opening.
6. Screw the buttery nut tight to secure the adaptor kit.
