RENTAL SERIES
ELECTRICAL GENERATOR
3.2.2.- DEEP SEA digital control module
If you purchased a generator unit with a DEEP SEA control module (models 5210 and 5310), the electrical
panel will look like the following diagram:
Image 6 - CONTROL PANEL FOR THE DEEP SEA CONTROL MODULE
Note: The button on the control module performs the same function as the diagnostic button (while in
OFF/AUTO mode).
DIAGNOSTIC
BUTTON
EARTH LEAKAGE
CIRCUIT
BREAKER
LOCK
ENGINE BLOCK
HEATER LIGHT
(YELLOW)
ELDON
XXXXXX
AMMETER
BATTERY
VOLTMETER
EMERGENCY
STOP
