3.2 .- CONTROL UNITS
The unit provided may be controlled by different modules depending on the type of function it has been designed
to perform.
The following is a generic control panel, which contains all of the electrical and mechanical options available.
Image 4 - GENERIC CONTROL PANEL
A
A
A
V
Hz
AMMETER
FREQUENCY METER
HOUR METER
VOLTMETER
LOCK
AUTO FUEL
REFILL SWITCH
LOCK
OIL PRESSURE
GAUGE
(OPTIONAL)
BATTERY
VOLTMETER
(OPTIONAL)
ENGINE TEMP.
GAUGE
FUEL GAUGE
EARTH LEAKAGE
CIRCUIT
BREAKER
AUTOMATIC
CONTROL UNIT
EMERGENCY
STOP
