6.- OPERATION MANUAL
The generator you purchased has been designed for manual service and thus starting and stopping the unit will be
done manually.
The following is a description of the different elements, according to the electrical generator chosen.
6.1.- ELECTRICAL PANEL COMPONENTS
A
AMMETER:
Measures the Intensity (A), by means of a switch, of the different phases of the electrical generator.
Hz
FREQUENCY METER:
Indicates the Frequency of the electrical generator (Hz).
V
VOLTMETER WITH ATS:
Indicates the Voltage (V), by means of a switch, of the different phases of the electrical generator.
HOUR METER:
ndicates number of hours worked by the electrical generator.
The two digits in red on the right indicate hundredths of hours. Hours are indicated in white from the third
digit on.
HORAS
