5. Troubleshooting
5.1 Blind rivet is not set
Cause Corrective measures
Battery switched off because it has been idle
for longer than 21 days
Place battery in the charger for 2 minutes
(see 3.4)
Battery discharged Charge battery; replace if necessary
Jaws (D) dirty or worn Clean and oil sliding surfaces or replace
(see 2.8)
Jaw mechanism loose Tighten (see 2.8)
Compression spring weakened (F) Replace
Tool does not operate when yellow trigger
button is pressed (red indicator light)
(see 5.3)
5.2 No spent mandrel disposal
Cause Corrective measures
Wrong nosepiece (A) used Exchange according to table (see 2.6)
Nosepiece worn (A) Replace
Mandrel jammed in jaws (D) Release mandrel, clean jaws and jaw
housing, oil sliding surface or replace jaws
(see 2.8)
Inside of steel head sleeve (B) dirty Clean (see 2.8)
Spent mandrel container (H) full Detach and empty
Passageway blocked Remove jammed mandrels and check for
trouble-free ejection (see 2.8)
5.3 Red lamp indicates fault
When pressing the trigger button
Cause Corrective measures
Riveting tool not in front end position Release trigger button
