Gesipa FireBird - 2 Blind Rivet Nut Setting Tool; Equipment;Accessories; Table of Contents; Spare Parts List

Contents page
1. Overview (drawing1 to 5) .................................................................................... 10
2. Blind rivet nut setting tool
2.1. Working capacity....................................................................................................... 10
2.2. Equipment/Accessories.............................................................................................. 10
2.3. Technical data............................................................................................................. 11
2.4. Threaded mandrels and nosepieces, rivet nuts per charge................................... 11
2.5. Safety instructions...................................................................................................... 11
2.6. Starting procedure..................................................................................................... 11
2.6.1. Adjustment of threaded mandrel x (drawing 2)......................................... 11
2.6.2. Stroke adjustment y (drawing 2).................................................................. 11
2.7. Operating procedure ................................................................................................. 12
2.7.1. Threading on a blind rivet nut....................................................................... 12
2.7.2. Setting a blind rivet nut.................................................................................. 12
2.7.3. Change of threaded mandrel 1 (drawing 3)................................................ 12
3. Charger and battery
3.1. Technical data............................................................................................................. 12
3.1.1. Charger ............................................................................................................ 12
3.1.2. Battery ............................................................................................................. 12
3.2. Safety instructions...................................................................................................... 12
3.2.1. Charger ............................................................................................................ 12
3.2.2. Battery ............................................................................................................. 13
3.3. Charging procedure................................................................................................... 13
3.4. Battery handling ........................................................................................................ 13
3.5. Environmental protection .......................................................................................... 13
4. Troubleshooting........................................................................................................... 14
5. Warranty........................................................................................................................ 14
6. Conformity declaration.................................................................................... 14
7. Spare parts drawing ................................................................................................ 77
8. Spare parts list ............................................................................................................ 77
10
2. Blind rivet nut setting tool
2.1. Working capacity
Blind rivet nuts from M3 to M8 in alu and steel
as well as M10 in alu.
2.2. Equipment/Accessories
Threades mandrel M6 in working
and nosepieces: position,
M4 and M5 in holder
M3, M8, M10
available as special
accessory on request
Wrench: 1 hexagon wrench SW4
Suspension loop: concealed in housing
Quick charger: 230 V AC, 50 Hz
Battery: 14,4 V DC
!
1. Overview (see drawing1-5; Page 3)
Pos. Description Drawing
1 Threaded Mandrel 2
2 Nosepiece 2
3 Lock Nut 2
4 Adjusting Nut 2
5 Lock Nut 2
6 Suspension Loop 1
7 Cap 1
8 Screw Driver 1
9 Accessories Container 1
10 Control Light 1
11 Trigger 1
12 Battery 1;5
13 Slide Lock 3
14 Charging Control Light 5
15 Battery Charger 5
16 Set Blind Rivet Nut 4
x Length of Threaded Mandrel 2
y Setting Stroke 2
z Grip Range 4
