Gesipa FireBird - 4 Troubleshooting; 5 Warranty; 6 Conformity Declaration

6. Conformity declaration
We hereby declare under our sole responsibility that these products meet following standards and
directives:
•
EN 50260
•
EN 60335
•
2006/42/EG
•
2006/95/EG
•
2004/108/EG
H.U. Harder
(Safety Officer)
4. Trouble shooting
4.1. Blind Rivet Nut is not threading on
Causes
– Nut thread faulty
– Threaded mandrel 1 faulty
– Blind rivet nut not touching nosepiece
– Blind rivet nut threads off again
– Battery empty
4.2. Set Blind Rivet Nut is loose
Causes
– Stroke y too short
– Trigger 11 released too early
4.3. Threaded mandrel is not
unthreading
Causes
– Wrong stroke adjustment
– Battery empty
Remedy
– take a new blind rivet nut
– Replace threaded mandrel 1
– wrong length ot threaded mandrel x adjust to
length of blind rivet nut (see 2.6.1.)
– hold blind rivet nut when threading on until tool
comes to a stop
– keep trigger 11 pressed until tool comes
to a stop
– charge, if necessary replace.
(see 3.3./3.4.)
Remedy
– adjust to larger stroke y (see 2.6.2.)
– keep trigger 11 pressed until automatic change-
over switching and threading out (see 2.7.)
Remedy
– Reduce stroke y (see 2.6.2.); if necessary un -
screw threaded mandrel with heaxagon screw
driver 8 (see drawing 1).
– recharge; if necessary replace
14
!
5. Warranty
This riveting tool has a 24 months warranty from the day of delivery (to be proved by invoice or
delivery note). Damage caused by common wearing, overloading or improper handling are excluded
from the warranty.
Damages caused by material or manufacturing faults will be covered by this warranty and will be re-
paired or replaced at no cost. Claims can only be accepted if the complete riveting tool (not stripped)
is returned to the distributor or GESIPA.
