61
Parts Specifications
Camera Front: 2 MP HD, fixed focus
Rear: 8 MP, autofocus, LED, video capture
NFC/RFID reader Contactless Combo NFC & RFID, supporting HF
Protocol: ISO 14443 –(A,B), MIFARE, ISO 15693
Power AC adapter
100 240VAC, 50/60Hz, 12V/2A, 24Watts
Battery pack Lithium-ion, 2100mAh x 4
Dimension (LxW×D) 239.5 x 155 x 29 mm (9.4 x 6.1 x 1.14 inch)
Weight 1500 g (3.3 lb)
Charging cradle USB 2.0 x 3, RJ45 (10/100 Mbps Ethernet) x 1, AC jack x 1
Button Functions on Special Occasions
On “POST/BIOS Setup/Non-ACPI” occasions, the five hardware buttons
provide keyboard key functions as described below.
Button Function
P1 Esc
P2 Tab
Enter
+
Up
–
Down
To Next Page
