Getac K120 User Manual

8
Blinks blue when the system is in Sleep mode.
Battery
Lights amber when the battery is being charged.
Lights green when battery charging is completed.
Ref
Component
Description
Blinks green to indicate the battery’s built-in high
temperature protection mechanism is activated.
CAUTION: Do not remove the battery during
this period.
Blinks red (once per second) when the battery’s capacity
is below 10%.
Blinks red rapidly (once per 0.5 second) when there
is a thermal protection problem. Ask for repair service
in case this happens.
Blinks amber when the battery charging is in an abnormal
state. Replace the battery in case this happens.
RF (Radio
Frequency)
Lights blue when the RF radio of any RF feature
(WLAN/Bluetooth/WWAN) is on.
Windows logo
button
Opens or closes the Start menu.
Plus button
Increases the sound volume.
Minus button
Decreases the sound volume.
P1 button
Opens or closes the OSD Control Panel.
When pressed longer:
Serves as the Ctrl+Alt+Del keyboard keys.
Fingerprint
scanner
Serves as the fingerprint verification, preventing
unauthorized access to your computer.
NOTE: The hardware buttons (except the power button) can be
re-defined using G-Manager.

Getac K120 Specifications

General

LED backlight	Yes
Display diagonal	12.5 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display brightness	1200 cd/m²
Native aspect ratio	16:9
Bus type	OPI
Stepping	Y0
Tjunction	100 °C
Processor code	SR3LA
Processor cache	6 MB
Processor cores	4
Processor model	i5-8250U
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor threads	8
Processor codename	Kaby Lake R
Processor frequency	1.6 GHz
Processor cache type	Smart Cache
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	42 x 24 mm
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
PCI Express configurations	1x2+2x1, 1x4, 2x2, 4x1
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Design Power (TDP)	15 W
Configurable TDP-down frequency	0.8 GHz
Internal memory	16 GB
Internal memory type	DDR4-SDRAM
Maximum internal memory	32 GB
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash)
Internal storage capacity	512 GB
Graphics card	UHD Graphics 620
Rear camera type	Single camera
Rear camera resolution (numeric)	8 MP
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Microphone in	-
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Device type	Tablet PC
Form factor	Slate
Product color	Black
Protection features	Shock resistant, Splash proof, Temperature proof, Vibration proof
International Protection (IP) code	IP65
Storage temperature (T-T)	-51 - 71 °C
Operating temperature (T-T)	-29 - 63 °C
Operating relative humidity (H-H)	0 - 95 %
Processor ARK ID	124967
Processor socket	BGA 1356
Keyboard language	German
AC adapter power	65 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Battery voltage	11.1 V
Battery capacity	2100 mAh
Battery life (max)	- h
Platform	Windows
Intel Trusted Execution Technology	No
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	47 mm
Width	340.5 mm
Height	307.5 mm
Weight	3250 g
