Getinge 86 SERIES Installation Manual

<Doc_INS><Doc_502606400><Rel_A><Lang_GB>
Page 6 of 20
INSTALLATION
The oor where the machine is to stand must be at and level within ±5 mm.
Pull the machine (on a transport pallet) to the location where it will be installed.
Lift the machine off the pallet.
Position the machine at the chosen location and adjust the feet so that the machine
is stable.
•
•
•
•
Bottom frame
V318
Figure 1. Adjustment
Using a spirit level, check as shown in Figure 1 that the machine is level within ±2 mm.
If you need to move the machine by using a pallet truck:
position the pallet truck forks as shown in Figure 2 so as not to damage the machine.
•
•
V1472
Figure 2. Positioning the pallet truck forks.
Level the
machine with
a spirit level.
Adjusting screwFoot plate
