Getinge 86 SERIES Installation Manual

<Doc_INS><Doc_502606400><Rel_A><Lang_GB>
Page 10 of 20
Connecting water, steam, waste and dryer
Installation may only be done by authorized personnel.
Provide water and, if required, steam connections with separate stopcocks. Flush
out the water and steam pipes that are to be connected to the machine, to prevent
clogging of lters and valves.
Connect the disinfector to cold and hot water and to steam and condensate connec-
tions, if used. The connections must meet the following requirements:
•
•
* Where the pressure is lower than 100 kPa a separate feeder pump must be used.
** At chamber depth = 720 mm
*** At chamber depth = 800 mm
Note:
Distilled or de-ionized water must have a conductivity of less than 40 µS/cm.
Connection Pressure Flow rate
Cold water 3/4” (20 mm) male 100-800 kPa
approx 33 liters/phase**
approx 40 liters/phase***
Hot water 3/4” (20 mm) male 100-800 kPa
approx 33 liters/phase**
approx 40 liters/phase***
Dist. water/
de-ion. water
3/4” (20 mm) male 100-800 kPa*
approx 33 liters/phase***
approx 40 liters/phase***
Steam 1/2” (15 mm) female 300-500 kPa
0.9 to 1.0 kg/min
(300 kPa)
Condensate 1/2” (15 mm) female
Compressed air 1/2” (15 mm) female 4 to 8 bar
