GEZE E 260 N4/1 User Manual

37
3.2 Fuses
Fused with either glass cartridge 5 x 20 mm (AT) fuses or automotive blade-type fu-
ses. The following fuses are used in the systems:
Only use glass cartridge fuses 5 x 20 mm (F1, F2, F8) as per EN 60127-2/3.
Only use glass cartridge fuses 5 x 20 mm (F1, F2, F8) as per EN 60127-2/3
Designation System N2/1 System N4/x
Mains fuse F1 0.8 A T 2 A T
Charger supply F8 0.8 A T 1.25 A T
Motor power supply F2 3.15 A T 5 A T
Battery fuse F3 3 A blade 5 A blade
Motor line 1 F4 3 A blade 4 A blade
Motor line 2 F5 - 4 A blade
Motor line 3 F6 - -
Motor line 4 F7 - -
Designation System N8/x System N12/x
Mains fuse F1 3.15 A T 4 A T
Charger supply F8 2 A T 2 A T
Motor power supply F2 10 A T 16 A T
Battery fuse F3 10 A blade 15 A blade
Motor line 1 F4 7.5 A blade 15 A blade
Motor line 2 F5 7.5 A blade 15 A blade (F6)
Motor line 3 F6 7.5 A blade -
Motor line 4 F7 7.5 A blade -
