Technical dataGC 363 R / SF
12 Technical data
Power supply: 12V to 24V, AC ±10%; 12V to 30V, DC ±10%
Power consump-
tion:
< 2.5W
Installation height: 2m to 3.5m
Temperature
range:
–25°C to +55°C, 0 to 95% relative humidity, non-condensing
Protection rating: IP54 according to EN 60529
Applicable direc-
tives:
R&TTE 1999/5/EC, MD 2006/42/EC, RoHS 2 2011/65/EU, LVD 2006/95/EC
Scanning mode: Movement Presence
Min. scanning speed: 5 cm/s Typical response time:
< 200ms (max. 500ms)
Technology: Microwave Doppler radar
Transmission frequency:
24.150GHz
Transmission power: < 20dBm EIRP
Density of transmission power:
< 5mW/cm
2
Active infrared control with back-
ground evaluation
Spot: 5cm x 5cm (typ.)
Number of light beams:
max. 24 per curtain
Number of curtains: 2
Output
(GC363 R):
Semiconductor relay (poten-
tial-free, polarity-free)
Max. switching current: 100mA
Max. switching voltage: 42V, AC/DC
Semiconductor relay (standard)
(potential-free, polarity-free)
Max. switching current: 100mA
Max. switching voltage: 42V, AC/DC
Holding time: 0.3 to 1s
Output
(GC363 SF):
Semiconductor relay (poten-
tial-free, polarity-free)
Max. switching current: 100 mA
Max. switching voltage:
42V, AC/DC
Semiconductor relay (standard)
(potential-free, polarity-free)
Max. switching current: 100 mA
Max. switching voltage:
42V, AC/DC
Holding time: 0.3 to 1s
Frequency output:
Pulsating signal (f = 100Hz ± 10%)
Current source output:
dc insulated current source active
Freeswing voltage: 6.5V
Output voltage at 10 mA: 3V min.
Typical load: up to 3 opto-couplers in series
Movement detection: Current source inactive
Idling voltage: < 500mV
