Commissioning GC 363 R / SF
16
5 Commissioning
5.1 Radar detector
X
Set the detection eld and sensitivity of the radar movement detector as
per AutSchR:
à Scanned eld = opening width x 1.5 m
à Movement speed from 10 cm/s must be detected
à The whole door width must be covered for escape and rescue
