25
Integrierte Schließfolgeregelung Slimdrive SD Türblattmontage Bandseite , Datei 88340 SD_IS-T-BS_180400.p65
Ordine e posizione degli elementi
anta fissa Slimdrive SD
(esempio)
anta mobile
Slimdrive SD-IS
Anta mobile DIN destra (
TS 5000
con
Slimdrive SD-IS
)
Anta mobile DIN sinistra (
Slimdrive SD-IS
con
Slimdrive SD
)
binario lungo
binario breve
anta mobile
Slimdrive SD-IS
anta fissa TS 5000
(esempio)
binario lungo
binario breve
